CCFL standard 225mm x 2.6mm (L x Ø) white

CCFL standard  225mm x 2.6mm (L x Ø) white
from 19,04 EUR
incl. 19 % tax excl.
Product No.:CFL26-0225s-s78
Dispatch time: 1 - 2 days

Quantity:

Properties

  • electrodes prepared as: tinned wire ends

Main applications

  • backlight lamp for 10.4" TFT panels
  • white design illumination with a bluish hue

Technical data

Massbild einer Kaltkathodenlampe


Mechanical
Tolerance
Diameter 2.6 mm +/- 0.1 mm
Length L 225 mm +/- 1 mm
Luminous length LL > 205 mm +/- 1 mm
Length of electrodes > 10 mm + 15 mm
Warm-up time 3 min -
Working temperature 0 bis + 50°C -
Storing temperature - 50 bis + 110°C -
Electrical
Working voltage 505 VRMS +/- 50 VRMS
Working current 5 mARMS + 1 mARMS
Power consumption 2525 mVA +/- 10 %
Sinusoidal AC 20 - 100 KHz -
Optical
Colour temperature 7800°K +/- 200°K
Visible colour white
-
Luminance 32000 cd/m2 +/- 5%
Lifetime 20000 h
-


Additional notes

CCFLs are made of glass, which is easily broken. The exchange of CCFL tubes and inverters requires certain technical skills. Our safety and handling instructions for inverters and CCFLs keep you up-to-date. We kindly ask you to read this instructions carefully, which can be found in the area: Information. Silicone cables and and silicone caps of the originally built-in CCFL can be re-used if in a good condition. If not re-usable we offer silicone replacement cables and caps and other hard to find parts in the area: CCFL -> Accessories.

As a replacement for

Notebook (TFT-panel): Compaq LTE 5xxx (Toshiba TM10C039)

TFT-panel: Sharp LM64C350, Sharp LQ10D367, Sharp LQ10S21,
Toshiba TM10C039

(Notes: The codevariable -x- subsumes similiar panels with the same CCFL. Listing is uncomplete and without warranty.)




Sliding-scale prices:

1-3 pcs per 19,04 EUR
4-19 pcs per 13,09 EUR
> 20 pcs per 11,52 EUR

This Product was added to our catalogue on Sunday, 11. March 2007.
