from 13,49 EUR

incl. 19 % tax excl.

Product No.:EL-Pbl-gr-18x74-sl
Dispatch time: 1 - 2 days

Quantity:

Properties

• high quality EL-panel with light off colour: grey and light on colour: blue-green

• all around lamination by factory for proper protection

• 2 solderable contacts

• overall dimensions(LxWxH): 18mm x 74mm x 0.42mm
• luminous dimensions(LxW): 16mm x 66mm
• lifetime >3000 hrs = 50% of initial brightness, useful lifetime >10.000 hrs

• luminance ~ 10 cd/m² (depends on voltage and frequency of inverter)
• EL-panel can be cut by scissors if you need a smaller luminating area
• watch the attached backlight exchange manual from below how to replace the EL-panel yourself
• shipping in a stiff and stable box to prevent a buckling of the EL-panel for a safe transport worldwide

• backlight EL-lamp for display of EMU EMAX II

• backlight EL-lamp for display of Kurzweil K1200 keyboard
• backlight EL-lamp for display of Roland Juno Alpha 1
• backlight EL-lamp for display of Roland Juno Alpha 2

• backlight EL-lamp for display of Roland MKS-80 keyboard
• backlight EL-lamp for display of Roland PG1000 programmer

• backlight EL-lamp for display of Sequential Circuits Prophet VS
• backlight EL-lamp for SHARP LCD LM16155
• backlight EL-panel in other keyboards
• backlight EL-panel in phones and telephone systems

• other replacement applications and machines like counters and measuring instruments

• ultra small and flat lighting applications like bell displays

• blue-green night light
• design and art objects
• light spots
• emergency lights

  (Notes: Application listing is uncomplete and without warranty.)


Sliding-scale prices:

1-4 pcs per 13,49 EUR
> 5 pcs per 10,71 EUR
